TECHNICAL PARAMETERS
|
|||||
| 5 TONS | 8 TONS | 10 TONS | 12 TONS | 16 TONS | |
|
Rated lifting weight
|
5000kg
|
8000kg
|
10000kg
|
14000kg
|
18000kg
|
|
Maximum lifting height
|
28m
|
30m
|
31m
|
36m
|
38m
|
|
Main lifting mechanism
|
8 ton winch
|
10 ton winch
|
12 ton winch
|
16 ton winch
|
|
|
Lifting operation mode
|
Push lever operation
|
7 ton winch
|
7 ton/10 ton winch
|
12 ton winch
|
|
|
Radius of rotation
|
1.7m
|
Push lever operation
|
|||
|
Swing speed
|
0-3rpm
|
2.3m
|
2.4m
|
2.65m
|
2.83m
|
|
Slewing bearing
|
1050mm turntable
|
1.2m turntable
|
1.3m turntable
|
1.45m turntable
|
|
|
Rear displacement top
|
There are
|
Standard
|
|||
|
Oil and electric dual-use
|
/
|
15kw-6pole copper core motor
|
|||
|
Protection device
|
Bidirectional hydraulic lock
|
||||
|
Work lamp
|
Two
|
||||
|
Boom
|
|||||
|
Boom structure type
|
5m*7sections
|
7m*5sections/6m*6sections
|
8m*5sections/
8m*6sections
|
8.5m*5sections
|
|
|
Total length of boom
|
35m
|
35m/36m
|
35m/40m
|
42m
|
|
|
Boom flat lying distance
|
/
|
15m(1 ton)
|
18m(1 ton)
|
22m(1 ton)
|
26m(1 ton)
|
|
Rod-out form
|
/
|
Synchronous scaling
|
|||
|
Hydraulic system
|
|||||
|
Hydraulic pump
|
Single pump(40#)
|
Single/Double pump
|
Double pump
|
Three pumps
|
|
|
Steering mechanism
|
Power steering (assist)
|
Hydraulic direction assist
|
|||
|
Slewing mechanism
|
Vertical type (with balancing valve)
|
Secondary planetary steering
|
|||
|
Reducer model
|
Planetary reducer
|
/
|
|||
|
Outrigger
|
|||||
|
Outrigger
|
5 full hydraulic legs
|
||||
|
Outrigger transverse span
|
5900mm
|
5080mm
|
6200mm
|
6760mm
|
6900mm
|
|
Outrigger longitudinal span
|
3400mm
|
4360mm
|
4500mm
|
5200mm
|
5500mm
|
|
Outrigger telescopic length
|
2m
|
1.5m
|
2m
|
2.2m
|
|
