Knuckle Crane

SPECIFICATION	5 Ton	8 Ton	10 Ton	12 Ton	16 Ton	20 Ton	24 Ton
Max. Load Moment(KN.m)	118	160	200	330	330	400	480
Max. Lifting Capacity(t/2m)	5	8	6.5	7.5t/3m	16	13	15
Max. Lifting Height(m)	12.1	13.2	13.2	17.2	15.7	17.6	17.7
Max. Working Radius(m)	10	11.2	11.2	15.1	13.5	15.4	15.6
Number of Telescopic Boom Sections	3	4	4	5	5	6	6
Slewing Angle	360°
Rated Working Pressure(Mpa)	30	28	28	28	28	28	30
Rated System Flow Rate(L/min)	34	60	60	60	64	84	80
Outrigger Span(m)	2290-5610	2330-5230	2330-5630	2330-5990	2330-7100	2330-7100	2330-7600
Crane Weight(kg)	2100	3800	4200	4600	5000	5700	5800
Installation Space(mm)	1000	1400	1420	1300	1530	1530	1530
